Brushless Electric Motors from the Market Leader of Propulsion Systems for Drones/UAVs
T-Motor offers Electric Motors of the highest Quality and Industrial Grade.
First Class Efficiency and Reliability are the Result of excellent Processing and Components. Manufacturers of UAVs for industrial operations can hardly do without the brand T-Motor.
Providing the Reliability Required for a Dependable Aerial Platform
Introduction of MN Series
With the Navigator design concept, the T-Motor Navigator Series is primarily used in aerial photography as the multirotor power system. The motor is a high-quality, smooth-running, durable brushless motor built for multirotor UAV applications. The custom assembly methods and components unique to the Navigator Series help provide the reliability required for a dependable aerial platform.
Upgraded Motor: 4225 to MN3508
According to extensive test data, the MN3508 is a flawless motor that has been upgraded from the 4225.
Flexible Mount Hole Design
The flexible mounting hole design accommodates various relevant parts for installing main props currently available on the market. It features flexible mounting holes compatible with many types of frames—standard 25mm x 25mm mounting holes.
The T-MOTOR MN3xxx Series adopts high-standard EZO bearings, originally imported. This improves the motors' lifespan. The higher quality of the bearings also ensures steady motor operation at low velocity, contributing to propeller stability during flight.
Included:
The package includes one set of prop adapters for M6. The surface of the prop adapter is knurled for added grip.
Notes: The 2pcs screw M3x12 are for installing the T-Motor CF prop with the plate cover and are not intended for mounting the motor to the frame.
| Manufacturer: |  |
| SKU: | 547 |
| GTIN: | 4251935111750 |
| Content: | 1,00 Pieces |
Specifications
- Test Item: MN3508 KV380
- Internal Resistance: 205mΩ
- Shaft Diameter: 4mm
- Stator Diameter: 35mm
- AWG: 18#
- Weight Including Cables: 103g
- Number of Cells (Lipo): 3-6S
- Max. Continuous Power 180S: 310W
- Configuration: 12N14P
- Motor Dimensions: Φ41.8 x 26.5mm
- Stator Height: 8mm
- Cable Length: 600mm
- Weight Excluding Cables: 82g
- Idle Current@10v: 0.4A
- Max. Continuous Current 180S: 14A
| Ambient Temperature | / | Voltage | DC Power Supplier | ||||||
| Item No. | Voltage (V) | Prop | Throttle | Current (A) | Power (W) | Thrust (G) | RPM | Efficiency (G/W) | Operating Temperature (°C) |
|
MN3508 KV380 |
14.8 |
T-MOTOR 14 x 4.8 CF |
50% | .1.3 | 19.24 | 350 | 2700 | 18.19 | 43 |
| 65% | 2.9 | 42.92 | 560 | 3500 | 13.05 | ||||
| 75% | 4 | 59.2 | 700 | 4000 | 11.82 | ||||
| 85% | 5.2 | 76.96 | 840 | 4500 | 10.91 | ||||
| 100% | 6.3 | 93.24 | 940 | 4700 | 10.08 | ||||
|
T-MOTOR 15 x 5 CF |
50% | 1.6 | 23.68 | 430 | 2600 | 18.16 | 45 | ||
| 65% | 3.4 | 50.32 | 670 | 3400 | 13.31 | ||||
| 75% | 5 | 74 | 820 | 3800 | 11.08 | ||||
| 85% | 6.4 | 94.72 | 1000 | 4200 | 10.56 | ||||
| 100% | 7.5 | 111 | 1100 | 4500 | 9.91 | ||||
|
T-MOTOR 16 x 5.4 CF |
50% | 2 | 29.6 | 440 | 2500 | 14.86 | 46 | ||
| 65% | 3.9 | 57.72 | 700 | 3300 | 12.13 | ||||
| 75% | 5.9 | 87.32 | 900 | 4000 | 10.31 | ||||
| 85% | 7.6 | 112.48 | 1100 | 4500 | 9.78 | ||||
| 100% | 9 | 133.2 | 1220 | 4800 | 9.16 | ||||
| 22.2 |
T-MOTOR 12 x 4 CF |
50% | 1.7 | 37.74 | 430 | 4400 | 11.39 | 40 | |
| 65% | 3.2 | 71.04 | 660 | 5400 | 9.29 | ||||
| 75% | 4.6 | 102.12 | 870 | 6200 | 8.52 | ||||
| 85% | 6.1 | 135.42 | 1040 | 6800 | 7.68 | ||||
| 100% | 7.1 | 157.62 | 1160 | 7300 | 7.36 | ||||
|
T-MOTOR 13 x 4.4 CF |
50% | 2.1 | 46.62 | 550 | 4300 | 11.80 | 47 | ||
| 65% | 3.7 | 82.14 | 810 | 5300 | 9.86 | ||||
| 75% | 5.5 | 122.1 | 1000 | 6000 | 8.19 | ||||
| 85% | 7.1 | 157.62 | 1300 | 6700 | 8.25 | ||||
| 100% | 8.4 | 186.48 | 1380 | 7040 | 7.40 | ||||
|
T-MOTOR 14 x 4.8 CF |
50% | 2.9 | 64.38 | 710 | 4300 | 11.03 | 63 | ||
| 65% | 5.3 | 117.66 | 1100 | 5300 | 9.35 | ||||
| 75% | 7.5 | 166.5 | 1350 | 5700 | 8.11 | ||||
| 85% | 9.8 | 217.56 | 1580 | 6000 | 7.26 | ||||
| 100% | 11.5 | 255.3 | 1730 | 6500 | 6.78 | ||||
|
T-MOTOR 15 x 5 CF |
50% | 3.6 | 79.92 | 820 | 3900 | 10.26 | 70 | ||
| 65% | 6.1 | 135.42 | 1200 | 4800 | 8.86 | ||||
| 75% | 9.5 | 210.9 | 1500 | 5300 | 7.11 | ||||
| 85% | 11.3 | 250.86 | 1700 | 5700 | 6.78 | ||||
| 100% | 13.3 | 295.26 | 1880 | 5900 | 6.37 | ||||
Notes: The test condition of temperature is motor surface temperature in 100% throttle while the motor run 10min.
- Test Item: MN3508 KV580
- Internal Resistance: 110mΩ
- Shaft Diameter: 4mm
- Stator Diameter: 35mm
- AWG: 18#
- Weight Including Cables: 103g
- Number of Cells (Lipo): 3-4S
- Max. Continuous Power 180S: 400W
- Configuration: 12N14P
- Motor Dimensions: Φ41.8 x 26.5mm
- Stator Height: 8mm
- Cable Length: 600mm
- Weight Excluding Cables: 82g
- Idle Current@10v: 0.4A
- Max. Continuous Current 180S: 18A
| Ambient Temperature | / | Voltage | DC Power Supplier | ||||||
| Item No. | Voltage (V) | Prop | Throttle | Current (A) | Power (W) | Thrust (G) | RPM | Efficiency (G/W) | Operating Temperature (°C) |
|
MN3508 KV580 |
14.8 |
T-MOTOR 12 x 4 CF |
50% | 2.2 | 32.56 | 360 | 4000 | 11.06 | 43 |
| 65% | 4.2 | 62.16 | 600 | 5200 | 9.65 | ||||
| 75% | 6.1 | 90.28 | 770 | 5900 | 8.53 | ||||
| 85% | 8 | 118.40 | 910 | 6500 | 7.69 | ||||
| 100% | 9.6 | 142.08 | 1050 | 7000 | 7.39 | ||||
|
T-MOTOR 13 x 4.4 CF |
50% | 2.6 | 38.48 | 450 | 4000 | 11.69 | 43 | ||
| 65% | 5 | 74.00 | 710 | 5200 | 9.59 | ||||
| 75% | 7 | 103.60 | 900 | 5700 | 8.69 | ||||
| 85% | 9.3 | 137.64 | 1120 | 6300 | 8.14 | ||||
| 100% | 11.3 | 167.24 | 1230 | 6600 | 7.35 | ||||
|
T-MOTOR 14 x 4.8 CF |
50% | 3.7 | 54.76 | 600 | 3800 | 10.96 | 55 | ||
| 65% | 7 | 103.60 | 930 | 4600 | 8.98 | ||||
| 75% | 9.7 | 143.56 | 1150 | 4900 | 8.01 | ||||
| 85% | 12.9 | 190.92 | 1350 | 5700 | 7.07 | ||||
| 100% | 15.2 | 224.96 | 1520 | 6100 | 6.76 | ||||
Notes: The test condition of temperature is motor surface temperature in 100% throttle while the motor run 10min.
- Test Item: MN3508 KV700
- Internal Resistance: 72mΩ
- Shaft Diameter: 4mm
- Stator Diameter: 35mm
- AWG: 18#
- Weight Including Cables: 104g
- Number of Cells (Lipo): 3-4S
- Max. Continuous Power 180S: 510W
- Configuration: 12N14P
- Motor Dimensions: Φ41.8 x 26.5mm
- Stator Height: 8mm
- Cable Length: 600mm
- Weight Excluding Cables: 82g
- Idle Current@10v: 0.5A
- Max. Continuous Current 180S: 23A
| Ambient Temperature | / | Voltage | DC Power Supplier | ||||||
| Item No. | Voltage (V) | Prop | Throttle | Current (A) | Power (W) | Thrust (G) | RPM | Efficiency (G/W) | Operating Temperature (°C) |
|
MN3508 KV700 |
11.1 |
T-MOTOR 12 x 4 CF |
50% | 2.3 | 25.53 | 280 | 3800 | 10.97 | 42 |
| 65% | 4.5 | 49.95 | 460 | 4900 | 9.21 | ||||
| 75% | 6.3 | 69.93 | 620 | 5300 | 8.87 | ||||
| 85% | 8.4 | 93.24 | 790 | 6000 | 8.47 | ||||
| 100% | 10.2 | 113.22 | 860 | 6400 | 7.60 | ||||
|
T-MOTOR 13 x 4.4 CF |
50% | 2.6 | 28.86 | 330 | 3600 | 11.43 | 44 | ||
| 65% | 5.2 | 57.72 | 560 | 4600 | 9.70 | ||||
| 75% | 7.4 | 82.14 | 720 | 5300 | 8.77 | ||||
| 85% | 9.8 | 108.78 | 880 | 5800 | 8.09 | ||||
| 100% | 12 | 133.20 | 1020 | 6200 | 7.66 | ||||
| 14.8 |
T-MOTOR 11 x 3.7 CF |
50% | 3.1 | 45.88 | 380 | 5300 | 8.28 | 41 | |
| 65% | 5.6 | 82.88 | 630 | 6500 | 7.60 | ||||
| 75% | 7.9 | 116.92 | 780 | 7200 | 6.67 | ||||
| 85% | 10.5 | 155.40 | 960 | 8000 | 6.18 | ||||
| 100% | 12.7 | 187.96 | 1110 | 8500 | 5.91 | ||||
|
T-MOTOR 12 x 4 CF |
50% | 3.8 | 56.24 | 460 | 4700 | 8.18 | 48 | ||
| 65% | 7.4 | 109.52 | 800 | 6300 | 7.30 | ||||
| 75% | 10 | 148.00 | 1000 | 6900 | 6.76 | ||||
| 85% | 13.5 | 199.80 | 1200 | 7500 | 6.01 | ||||
| 100% | 16.1 | 238.28 | 1360 | 8100 | 5.71 | ||||
Notes: The test condition of temperature is motor surface temperature in 100% throttle while the motor run 10min.
