T-Motor MN801-S Brushless Electric Motor KV150

249,99 €
incl. 19% VAT , plus shipping costs
  • Born for VTOL
  • Long Service Life
  • Excellent Cooling Power
  • Water- and Dust Resistance
  • Anti Corrosion

  • Motor Constant KV

Pcs
Bestellung auf Anfrage

Delivery time: ca. 3 weeks




Brushless Electric Motors from the Market Leader of Propulsion Systems for Drones/UAVs

T-Motor offers Electric Motors of the highest Quality and Industrial Grade.
First Class Efficiency and Reliability are the Result of excellent Processing and Components. Manufacturers of UAVs for industrial operations can hardly do without the brand T-Motor.



Heavy load motor born for VTOL - MN801S



  • 12+ kg Thrust
  • Stable & Reliable
  • Safe
  • Impact resistant
  • IP45



Cooling design - Soaring in the hot sky

Centrifugal fan design of bell cap actively cools the motor; Divergent and upward fin design of motor base enlarges the heat dissipation area. Heat dissipation performs 15% better than ordinary motors.

Manual winding with special varnished wires of high temperature resistance.

Magnets of high temperature resistance are employed for motor heat and overload resistance

  • Excellent cooling performance
  • Anti-high temperature
  • Anti-overload



Protection Grade: IP45 - Enjoy flying regardless environment

Semi-closed design is introduced to MN801S.

Grid-shaped structure of bell cap allows efficient ventilation while protects motors from dust and other debris.

The grid-shaped inlet holes on the base further keeps motors away from foreign objects even when motors are mounted upside down.

Alloy shaft, bearing, varnished wires, silicon steel sheet, magnet and bell are treated with the latest anti-rust and anti-corrosion technology. It grants the motor parts remarkable protection.



Locking method - Safe flying with MN801S

T shape shaft secured with a circlip and a screw ensures safety and reliability under high RPM and power without rotor looseness.



Operation system - Big thrust, long lifespan

A 12mm steel shaft and 24mm big bearings are adopted to MN801S which renders outstanding impact resistance, stability and lifetime.



Performance optimization - We value every gram

Anti-high temperature curved magnets with precise tolerance control and rational magnet space for optimal motor magnetic circuit helps improve motor performance by 5%+.

Manufacturer: T-Motor
SKU: TMOM0200-KV150
GTIN: 6971360350026
Content‍: 1,00 Pieces

Specifications - MN801S



  • Motor Size: ⌀89 x 39,4mm
  • Stator: Imported silicon steel sheet; Anti-rust treatment; 150°C high temperature-resisting coatings
  • Configuration: 24N28P
  • Shaft Diameter: IN: 12mm, OUT: 8mm
  • Bearing: Imported 6901ZZ
  • Magnet Level: 180°C high temperature resistance
  • Silicon Cable: 14AWG x 150mm
  • Copper Wire: 220°C high temperature resistance: Level C
  • Coil Insulation Test: 500V
  • Centrifugal Cooling Design: YES
  • Rotor Dynamic Balance Standard: ≤ 5Mg
  • Motor Dynamic Balance Standard: ≤ 10Mg
  • IP: IP45
  • Accessories
    • 4pcs M3 x 14mm Mounting Screw
    • 1pcs Prop Installation Screw
    • 4pcs M4 x 12mm Motor Mounting Screw
    • 1pcs Cover





  • KV: 120
  • Idle Current (18V): 1.1A
  • Peak Current (180S): 45A
  • Max. Power (180S): 2200W
  • Internal Resistance: 80mΩ
  • Rated Voltage (Lipo): 6-12S
  • ESC Recommendation: FLAME 60A HV
  • Propeller Recommendation: 28-29"
  • Motor Weight (incl. Cable): 470g
  • Package Weight: 600g



  • KV: 150
  • Idle Current (15V): 1.4A
  • Peak Current (180S): 60A
  • Max. Power (180S): 2800W
  • Internal Resistance: 50mΩ
  • Rated Voltage (Lipo): 6-12S
  • ESC Recommendation: FLAME 60A / 80A HV
  • Propeller Recommendation: 26-27"
  • Motor Weight (incl. Cables): 480g
  • Package Weight: 600g





Test Report - MN801S



Item No. Propeller Throttle Voltage (V) Current (A) Input power (W) RPM Torque (N*m) Thrust (g) Efficiency (g/W) Operating Temperature

MN801S

KV120

T-MOTOR

G28 x 9.2 CF

40% 47.81 5.42 259.08 1930 0.85 3083 11.90

78,5°C

(Ambient temperature: 0°C)

42% 47.81 5.84 279.18 1984 0.91 3259 11.67
44% 47.83 6.45 308.67 2076 0.98 3506 11.36
46% 47.83 7.05 337.27 2174 1.04 3724 11.04
48% 47.84 7.74 370.07 2264 1.11 3985 10.76
50% 47.84 8.48 405.76 2356 1.19 4247 10.47
52% 47.82 9.12 436.29 2432 1.28 4477 10.26
54% 47.82 9.91 473.94 2512 1.35 4746 10.01
56% 47.82 10.74 513.59 2597 1.43 5010 9.75
58% 47.82 11.62 555.78 2676 1.51 5299 9.53
60% 47.82 12.47 596.46 2775 1.58 5566 9.33
62% 47.83 13.36 639.11 2857 1.66 5816 9.10
64% 47.83 14.30 683.80 2942 1.74 6085 8.89
66% 47.85 15.24 729.18 3020 1.81 6329 8.68
68% 47.85 16.90 808.65 3138 1.94 6769 8.37
70% 47.80 17.92 856.56 3204 2.03 7059 8.24
75% 47.79 20.63 985.85 3396 2.24 7721 7.83
80% 47.80 23.59 1127.63 3567 2.45 8402 7.45
90% 47.81 30.65 1465.23 3903 2.90 9924 6.77
100% 47.83 40.28 1926.68 4277 3.44 10472 5.43



Item No. Propeller Throttle Voltage (V) Current (A) Input power (W) RPM Torque (N*m) Thrust (g) Efficiency (g/W) Operating Temperature

MN801S

KV120

T-MOTOR

G29 x 9.5 CF

40% 47.91 6.14 294.33 1900 1.25 3662 12.44

109.5°C

(Ambient temperature: 0°C)

42% 47.91 6.67 319.74 4956 1.31 3880 12.13
44% 47.91 7.35 352.04 2054 1.40 4154 11.79
46% 47.91 8.05 385.82 2130 1.48 4397 11.39
48% 47.91 8.79 421.03 2208 1.57 4694 11.15
50% 47.92 9.61 460.32 2293 1.66 4976 10.81
52% 47.91 10.48 502.19 2376 1.75 5284 10.52
54% 47.91 11.27 539.67 2451 1.84 5557 10.30
56% 47.93 12.23 586.33 2530 1.94 5891 10.04
58% 47.93 13.33 638.86 2610 2.05 6247 9.78
60% 47.93 14.36 688.32 2684 2.15 6596 9.58
62% 47.93 15.46 740.75 2777 2.26 6930 9.35
64% 47.93 16.54 792.63 2854 2.35 7205 9.09
66% 47.93 17.64 845.20 2930 2.45 7515 8.89
68% 47.93 18.77 899.48 3108 2.55 7796 8.67
70% 47.93 20.72 993.17 3178 2.70 8277 8.33
75% 47.92 23.77 1139.15 3372 2.94 9108 7.99
80% 47.92 27.35 1310.37 3437 3.19 9793 7.47
90% 47.92 37.77 1809.82 3774 3.73 10426 5.76
100% 47.92 48.79 2337.56 4045 4.16 11683 4.99



Item No. Propeller Throttle Voltage (V) Current (A) Input power (W) RPM Torque (N*m) Thrust (g) Efficiency (g/W) Operating Temperature

MN801S

KV150

T-MOTOR

G26 x 8.5 CF

40% 47.91 7.03 336.95 2616 0.83 3509 10.41

86.5°C

(Ambient temperature: 0°C)

42% 47.91 7.72 369.74 2702 0.90 3735 10.10
44% 47.91 8.54 409.01 2826 0.98 4028 9.84
46% 47.91 9.39 449.90 2928 1.05 4317 9.59
48% 47.90 10.28 492.44 3070 1.13 4604 9.34
50% 47.92 11.91 570.53 3174 1.27 5057 8.86
52% 47.90 12.64 605.53 3302 1.33 5275 8.71
54% 47.90 13.76 659.08 3438 1.42 5574 8.45
56% 47.91 14.79 708.58 3584 1.51 5878 8.29
58% 47.90 15.88 760.86 3697 1.59 6219 8.17
60% 47.90 17.07 817.41 3798 1.69 6383 7.81
62% 47.91 18.29 875.99 3912 1.78 6770 7.73
64% 47.91 19.40 929.45 4029 1.86 7033 7.57
66% 47.90 20.76 994.38 4148 1.95 7360 7.40
68% 47.90 22.09 1057.76 4278 2.04 7710 7.28
70% 47.90 23.45 1123.18 4369 2.13 8005 7.12
75% 47.89 27.02 1293.75 4496 2.35 8754 6.76
80% 47.85 30.86 1476.30 4525 2.59 9604 6.50
90% 47.79 40.20 1920.91 4806 3.10 10724 5.58
100% 47.76 57.34 2738.05 5247 3.75 12076 4.41

Note: Motor temperature is motor surface temperature @100% throttle running 10 mins.

(Data above based on benchtest are for reference only. Comparison with that of other motor types is not recommended.)
