Carbon fibre propeller from the market leader of industrial propulsion systems for Drones/UAVs
T-Motor provides carbon fibre propellers of highest quality and industrial grade. The propellers perfectly match T-Motor' electric motors. Combined, they offer first class efficiency and reliability. Manufacturer of UAVs for an industrial environment can barely do without the brand T-Motor.
- All specifications are based on manufacturer information -
Important! The notes below must be followed:
-
Please make sure that screws of cover plate and propeller are mounted properly
-
Double check that propellers are flawless. Otherwise, replace them before flight
-
Fall-off or similar physical impact will lead to deformation or cracks. In this case, replacement of propellers is required
-
Never add force onto the propellers or decompose them. Any decomposition will result in safety issues
-
For safety, please stay away from spinning propellers. Special attention should be paid to when the propellers are in use
-
Please keep the propellers aways from hostile environments containing corrosive gases, and maintain strict compliance with storage temperature and humidity requirements
Specifications
- Diameter / Pitch: 24" *11 (812.8mm x 279.4mm)
- Weight (single propeller): 129 gram
- Material: CF+Epoxy
- Surface Treatment: Glossy
- Propeller type: 2blades-intergrated
- Working temperature: -40°C ~ 65°C
- Storage temperature: -10°C ~ 50°C
- Storage humidity: < 85%
- Optimum RPM: 1200 - 3000 RPM/min
- Thrust limitation: 35 kg
Warning
- Please make sure that screws of cover plates and propellers are mounted properly.
- Double check that propellers are flawless. Otherwise, please replace them before flight.
- Fall-off or equivalent impact to propellers will lead to deformation or cracks. In this case, you will need to replace them.
- NEVER add force onto the propellers or decompose the propellers. Any decomposition will result in safety issues.
- For safety, please stay away from the spinning propellers. Special attention should be paid to when using the propellers.
- Please keep the propellers away from hostile environments containing corrosive gases, and maintain strict compliance with storage temperature and humidity requirements, especially when it comes to long-time storage
* All the information above are for reference
