| Item information | Value |
|---|---|
| Manufacturer: |  |
| SKU: | M408 |
| GTIN: | 6,94157E+12 |
Specifications
OcuSync Technical Data
| Operating Frequency Range | 5.150 to 5.250 GHz, 5.725 to 5.850 GHz |
| Radiated Power (EIRP) | 2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC) |
| 5.1 GHz: < 23 dBm (FCC/CE) | |
| 5.8 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC) | |
| Wi-Fi | 802.11 a/b/g/n/ac/ax |
| Operating Frequency Range | 2.4000 to 2.4835 GHz, 5.150 to 5.250 GHz, 5.725 to 5.850 GHz |
| Radiated Power (EIRP) | 2.4 GHz: < 26 dBm (FCC), < 20 dBm (CE/SRRC/MIC) |
| 5.1 GHz: < 26 dBm (FCC), < 23 dBm (CE/SRRC/MIC) | |
| 5.8 GHz: < 26 dBm (FCC/SRRC), < 14 dBm (CE) | |
| Bluetooth | Bluetooth 5.2 |
| Operating Frequency | 2.4000 to 2.4835 GHz |
| Radiated Power (EIRP) | < 10 dBm |
General Data
| Model | TKPL2 |
| Battery Type | Li-Ion (6500 mAh at 7.2 V) |
| Chemical Composition | LiNiCoAIO2 |
| Recommended USB-C Charger | Maximum rated power: 100 W |
| Nominal Power | 12.5 W |
| GNSS | GPS + Galileo + BeiDou |
| Video Output | HDMI Type-A |
| Operating Temperature | -20°C to +50°C |
| Storage Temperature | Within one month: -30°C to +45°C |
| One to three months: -30°C to +25°C | |
| Three months to one year: -30°C to +30°C | |
| Charging Temperature | 5°C to 40°C |
Note: The permissible operating frequency varies by country and region. Please refer to local laws and regulations for more Details.
