DJI D-RTK 2 - Mobile Station GNSS-Reference Station

General

D-RTK 2 Mobile Station is DJIs upgraded high-precision GNSS receiver that supports all major global satellite navigation systems, providing real-time differential corrections that generate centimeter-level positioning data for improved relative accuracy. With the DJI RTK 2 you benefit from the Real-Time Kinematic (RTK) technique, which provides even more accurate GNSS positioning data.

Highlights

• Quick and easy installation on site
• Generation of centimeter-level position data
• Simultaneous use of up to 5 drones possible
• Stabel data transmission for efficient mission coordination
• Robust yet lightweight carbon fiber design with IP65 protection rating

Possible Applications

• Ground mapping with photogrammetry
• Area and building surveys
• Industrial inspections
• Monitoring of building sites & positioning of equipment

System Description

Centimeter-level Positioning

D-RTK 2 Mobile Station fully supports GPS, GLONASS, Beidou, and GALILEO signals. Easy and quick to set up, the D-RTK 2 Mobile Station provides real-time differential data for drones to achieve centimeter-level positioning accuracy. The built-in high-gain antenna offers better signal reception from more satellites even when obstructions are present.

Stay Connected for Any Mission

D-RTK 2 Mobile Station supports communication via 4G, OcuSync, WiFi, and LAN, ensuring uninterrupted, stable data transmission under any application scenario. Up to 5 remote controllers can be connected to D-RTK 2 Mobile Station simultaneously. This makes coordinated operations involving multiple drones a possibility, significantly improving efficiency.

Durability You Can Trust

Featuring IP65 level ingress protection (dust-protected, and a lightweight carbon fiber body, the D-RTK 2 Mobile Station is ultra-portable and up for any task, no matter how tough. The built-in IMUs monitor movements and calibrate the tilt sensors to alert the operator of any abnormalities during the mission, minimizing risks.

A Comprehensive Solution

D-RTK 2 Mobile Station is compatible with Phantom 4 RTK and MG-1P RTK as well as M300 RTK and M210 RTK. It can be used as a Continuously Operating Reference Station (CORS), which provides high precision positioning data within the cover range of the base station, making it the ideal tool for surveying, aerial inspections, agriculture, and other industrial applications.

In the Box

• 1 x D-RTK 2 Mobile Station

Compatibility

• Phantom P4 RTK
• MG-1P RTK (Agras MG-1P Serie)
• M300 RTK
• M210 RTK

Please note:
Simultaneous use of multiple remote controls is only possible using MG-1P and P4 RTK standard remote controllers.
