Brushless Electric Motors from the Market Leader of Propulsion Systems for Drones/UAVs
T-Motor offers Electric Motors of the highest Quality and Industrial Grade.
First Class Efficiency and Reliability are the Result of excellent Processing and Components. Manufacturers of UAVs for industrial operations can hardly do without the brand T-Motor.
Light & Tidy - Explosive Thrust
- Energetic & Powerful
- 8700g at 100% Throttle
- Max. Power: 2400W
* Data obtained on ASL 0
High Temperature & Overload Resistance
Environmental Adaptability
- Sand-Proof
- Heat Resistant
- Water-Proof
- Dust-Proof
- Anti-Corrosion
* IP45 as per IEC 60429 after testing under controlled conditions.
V505 Recommendations
- VTOL Prop: P16 x 5.4
- Thrust Motor: AT4120KV250
- AUW: 12KG
- ESC: Flame 60A HV
- Voltage: 12S
- Payload: 1KG
(With 12s 4300 mAh-5000mAh battery for VTOL, estimated flight time is 3-4 mins.
With 12s 17500mAh or 6s 35000mAh battery for cruising, estimated flight time is 2 hours.)
V605 Recommendations
- VTOL Prop: P22 x 7.4
- Thrust Motor: AT5230KV200
- AUW: 20KG
- ESC: Flame 80A HV
- Voltage: 12S
- Payload: 3KG
(With 12s 8000mAh battery for VTOL, estimated flight time is 3-4 mins.
With 12s 28000mAh or 6s 35000mAh battery for cruising, estimated flight time is 2 hours and 20 minutes)
* The estimated flight time is for reference only.
| Manufacturer: |  |
| SKU: | TMOM0400 |
| GTIN: | 4251935114775 |
| Content: | 1,00 Pieces |
Specifications:
- Stator: Imported silicon steel sheet;Anti-rust treatment;180°C high temperature-resisting coatings
- Bearing: Imported 696ZZ
- Magnet Level: 150°C high temperature resistance
- Copper Wire: 220°C high temperature resistance: Level C
- Coil Insulation Test: 500V
- Centrifugal Cooling Design: YES
- Rotor Dynamic Balance Standard: <<5Mg
- Motor Dynamic Balance Standard: <<10Mg
- IP: IP45
- Accessories:
- M3x12mm Mounting Screw x2
- Cover x1 M4x10mm Motor Mounting Screw x4
- Test Item: KV210
- Motor Dimensions: Ø68.8x39.9mm
- Lead: 16AWGx150mm
- Shaft Diameter: IN:6mm,OUT:6mm
- Idle Current(17V): 1.6A
- Max. Power(180s): 3200W
- Weight (Incl. Cable): 320g
- Internal Resistance: 48mΩ
- Configuration: 24N28P
- Rated Voltage (Lipo): 12S
- Peak Current (180s): 70A
- Recommendation: FLAME80A+V22x7.4
Test Report
| Type | Propeller | Throttle |
Voltage (V) |
Thrust (g) |
Torque (N x m) |
Current (A) |
RPM |
Power (W) |
Efficiency (g/W) |
Operating Temperature (°C) |
|
V6055 KV210 |
T-MOTOR V22 x 7.4
|
40% | 47.90 | 2898 | 0.73 | 7.21 | 3444 | 345 | 8.39 |
98°C (Ambient Temperature: 22°C) |
| 42% | 47.88 | 3200 | 0.80 | 8.20 | 3592 | 393 | 8.15 | |||
| 44% | 47.86 | 3464 | 0.86 | 9.09 | 3762 | 435 | 7.96 | |||
| 46% | 47.83 | 3722 | 0.93 | 10.29 | 3908 | 492 | 7.56 | |||
| 48% | 47.80 | 4059 | 1.02 | 11.56 | 4063 | 552 | 7.35 | |||
| 50% | 47.77 | 4385 | 1.09 | 12.94 | 4226 | 618 | 7.09 | |||
| 52% | 47.75 | 4663 | 1.16 | 14.12 | 4352 | 674 | 6.91 | |||
| 54% | 47.72 | 4995 | 1.24 | 15.46 | 4488 | 738 | 6.77 | |||
| 56% | 47.70 | 5266 | 1.31 | 16.76 | 4618 | 800 | 6.59 | |||
| 58% | 47.67 | 5525 | 1.36 | 18.00 | 4734 | 858 | 6.44 | |||
| 60% | 47.63 | 5788 | 1.44 | 19.49 | 4859 | 927 | 6.24 | |||
| 62% | 47.60 | 6153 | 1.52 | 21.06 | 4980 | 1003 | 6.14 | |||
| 64% | 47.58 | 6455 | 1.60 | 22.61 | 5107 | 1076 | 6.00 | |||
| 66% | 47.53 | 6771 | 1.68 | 24.51 | 5241 | 1165 | 5.81 | |||
| 68% | 47.49 | 7049 | 1.75 | 26.19 | 5363 | 1244 | 5.67 | |||
| 70% | 47.45 | 7383 | 1.84 | 28.11 | 5487 | 1334 | 5.53 | |||
| 80% | 47.23 | 9108 | 2.28 | 38.69 | 6025 | 1827 | 4.98 | |||
| 90% | 46.95 | 10917 | 2.80 | 52.16 | 6561 | 2449 | 4.46 | |||
| 100% | 46.60 | 12671 | 3.26 | 68.30 | 7036 | 3183 | 4.01 |
Note: Motor temperature is motor Surface temperature @80% throttle running 10mins.
(Data above based on benchtest are for reference only, comparison with that of other motor types is not recommended.)
